FEATURES AND TECHNICAL SPECIFICATIONS

Features/Advantages:

	Working capacity of 250 psi assures proper working conditions and equipment performance
	High pressure engine kick-out increases engine life and lowers fuel consumption
	Air filtration on receiver ensures clean air supply
	All components of Darby Portable Air Compressors can be sold separately for use on tack rig or other applications
	Murphy control Panel
	Pulley driven compressor with 3 rib Powerband matched belt for longer life
	Darby air compressors are engineered and designed to operate all Darby related pneumatic equipment such as bending mandrels, internal line-up clamps and other high-pressure equipment

Technical Specifications:

Length	72" (1829 mm)
Width	48" (1219 mm)
Height	78" (1981 mm)
Weight	2700 lbs (1145 kg)
Engine	Cat C1.1 Diesel Engine
Air Compressor	Quincy 340 Air Compressor
Horsepower	30 hp
CFM	29.2 cfm
Fuel Tank	18 gal 68 L)
