FEATURES AND TECHNICAL SPECIFICATIONS

Features/Advantages:

	Adjustable for any wall thickness within specified mandrel range. Can cover 2 pipe sizes through use of conversion kits.
	Wedges that are case hardened and bolt on to the wedge plates
	Long wedges reduce the need for shimming
	Grade 8 bolts and the highest quality Parker seals and u-cups
	Tapered wheels eliminate rolling
	Slide locks pull the belly of the mandrels up to eliminate drag in the pipe
	High horsepower air motors for quick and responsive travel
	Powerful oversized cylinders provide maximum force
	Equipped with filters, lubricators, regulators & valves that are all rated to 250 psi
	Remote operated by reach rod

Performance:

	High strength alloys used in construction
	Specifically designed for use in a larger bending machine (16" - 30" and up)

Technical Specifications:

Length	107" (2718 mm)
Width	12" (305 mm)
Height	16" (406 mm)
Weight	930 lbs (421 kg)
Air Motor	.9 hp - Cooper
Cylinder	6" (152 mm)
Working Air Pressure	180 - 210 psi
Pipe Size Range	16" (406 mm)
Wall Thickness Range	.188" - .500" (4.8 - 12.7 mm)
